In addition to ordinary stereo recording, it is possible to record up to four channels simultaneously which can then be mixed down to a stereo signal. Recordings can be made at 44.1/48/96 kHz, 16/24-bit in WAV or BWF format. The recorder features Tascam original HDDA microphone preamps which are known for high S/N ratio, low input-referred noise and low distortion. It can be mounted directly to the camera and offers various audio inputs and outputs to allow the recording of high-resolution audio material in parallel to, but separated from the camera and its video data. Should be fine for the rest.The DR-60D MKII is a compact 4-track audio recorder for dedicated use with a digital single-lens reflex (DSLR) or digital single-lens mirrorless (DSLM) camera as a video system.
Get the ground right by testing for a short or very low ohms between ct and common point as above. They may double up the din pins I.e pins 1&2= 11.5v, 3&4 = ct etc. Should be easy to figure out from inside too as the centre tap of the transformer will go to ground ( 0vdc, common, ground or sleeve if any jack socket) the other two wires connect to the rectifier circuit and can be either way around since it's AC. The multi- pin din plug will simply be something like (pin 1= 11.5, pin3=ct or 0v, pin 5 = 11.5) Manufacturers love to use odd values like 11.5v so people think that it won't work unless you have exactly 11.5v x2, in other words, their supply. The DC conversion and regulation is handled inside the recorder.Īn extra 0.5v won't hurt at all and a 35 or 40 VA tranny is fine, could even go 30 VA since you have the extra.
This actually makes it even simpler if you can't find a supply.Ī transformer with a 12-0-12 secondary winding ( 24v with center tapping) and a VA rating of 32 VA (which gives you roughly 1250mA). What you are looking at there is an AC center-tapped supply.
